8.6 Cartridge emulation

$D596: SDX Conﬁguration (r/w)

7 6 5 4 3 2 1 0

- - - - - - config

00 SpartaDOS X deactivated

01 SpartaDOS X in freezer RAM starting at bank 0

10 SpartaDOS X in ﬂash ROM starting at bank 0

11 SpartaDOS X in ﬂash ROM starting at bank 64

8.6.2.1 Additional registers in 8k mode with TURBO FREEZER 2005 bank

switching

$D540. . . $D57F: Bank Select (r/w)

7 6 5 4 3 2 1 0

- - - - - - - -

A read or write access to this area selects the bank. An access to address $D540 selects

bank 0, $D541 selects bank 1, . . . , $D57F selects bank 63. If the bank register $D590 is

set to a bank in the range 64. . . 127, then $D540. . . $D57F will refer to the banks 64. . . 127

instead of the banks 0. . . 63.

$D580: Cart Disable (r/w)

7 6 5 4 3 2 1 0

- - - - - - - -

A read or write access to this register disables the module.

$D581: Cart Enable (r/w)

7 6 5 4 3 2 1 0

- - - - - - - -

A read or write access to this register enables the module.

$D584: Write Disable (r/w)

7 6 5 4 3 2 1 0

- - - - - - - -

A read or write access to this register disables write access to the module.

$D585: Write Enable (r/w)

7 6 5 4 3 2 1 0

- - - - - - - -

A read or write access to this register enables write access to the module.
